Transmission protocol
ipcolor
Distribution mode
1 IN 2 OUT
Transmission distance
CAT6/6A/7≤70m
HDMI Resolution
480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz, 1280x960, 1280x800, 1280x768, 1680x1050, 1360x768, 1366x768, 1600x900, 1024x768, 800x600, 3840x2160@24/25/30/50/60Hz, 4096x2160@24/25Hz
Audio formats
LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1
IR
Bi-directional IR passback (20-60khz)
RS-232
3 pin: GND-RxD-TxD, follows RS-232 levels
Working temperature
-20~60℃
Storage temperature
-30~70℃
Humidity (no condensation
0~90% RH
Protection
ESD protection
1a Contact discharge level 2
1b Air discharge level 3
Implementation of the standard: IEC61000-4-2
Lightning protection
Surge protection
Power supply
TX: DC 12V/2A
RX: DC 5V/2A
Power consumption
TX<9W
RX＜4W
Material
Iron
Color
Black
Weight
TX: 650g
RX: 243g
Dimension
TX: 265.0(L) x 104.0(W) x 23.0(H) mm
RX: 105.5(L) x 102.5(W) x 20.0(H) mm
