Voltage/Current
Micro USB power supply (5V/1A)
Power consumption
TX < 4.5W, RX < 3.5W
HDMI version
HDMI 2.0
HDCP version
HDCP 1.4/HDCP 2.2
Max transmission rate
18Gbps
Resolution supported
3840x2160@24/30/50/60Hz (YUV 4:4:4, YUV 4:2:2 and RGB),1080P@50/60Hz, 720P@50/60Hz, 1920x1200@60Hz
Input and output TMDS signal
0.7~1.2Vp-p（TMDS）
Input and output DDC signal
5Vp-p（TTL）
Wi-Fi Frequency bands
5.18-5.24 GHz
Transmission distance
≤ 20m
Latency
100~250ms
Connection types
One to one
SSID pairing
Supported
ESD protection
1a Contact discharge level 3 1b Air discharge level 3 Standard: IEC61000-4-2
Working temperature
-20~50℃
Storage temperature
-30~70℃
Humidity (no condensation)
0~90% RH
Dimension
TX: 40.2(W) * 230(L) * 15.0(H)mm
RX: 40.2(W) * 230(L) * 15.0(H)mm
Color
Black
Material
ABS
Net weight
TX: 58g; RX: 54g
