HDMI Input
1x HDMI
HDMI Output
2x HDMI
Compatibility
HDMI 2.1, HDMI2.0, HDMI1.4
HDCP 2.3, HDCP2.2, HDCP1.4
Maximum transmission rate
48Gbps
Resolutions
7680x4320@24/25/30/50/60Hz 3840x2160@24/25/30/50/60/120Hz 1080p@24/25/30/50/60/120Hz 720p@50/60/100/120Hz
Video signal
EDID passthrough, auto downscaling
Video signal
HDR10/HDR10+/Dolby Vision
Video signal
HDMI 3D
Video signal
HDMI CEC
Video signal
VRR, Free Sync, G-Sync
S/PDIF Output
Dolby Atmos, Dolby True HD, DTS:X, DTS-HD, etc.
HDMI Output
Dolby Atmos, Dolby Digital 7.1CH, Dolby True HD, DTS:X, DTS-HD, LPCM 7.1CH, etc.
Power Supply
DC5V/1A
Power Consumption
＜4W
Working temperature
-20℃~60℃
Storage temperature
-30℃~70℃
Humidity
0~90%RH（No condensation）
Housing
Iron
Weight
200g
Color
Black
Dimensions
135.0(L)*54.0(W)*16.5(H)mm
Protection
ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
