HDMI Input
1x HDMI
HDMI Output
4x HDMI
Compatibility
HDMI 2.0
HDCP 1.4/HDCP 2.0
Resolutions
input: 3840x2160@60/50/30/25/24Hz; 1080P@60/50/30/25/24Hz
output: up to 3840x2160@60Hz
3.5mm Output
LPCM 2.0
HDMI Output
Dolby Digital 5.1CH /DTS 5.1CH/LPCM 2.0
Mode
1x1/1x2/1x3/1x4/2x1/3x1/4x1/2x2
RS-232 (GND/ RxD/TxD)
Default baud rate: 9600 Only when the dip switch is set to ‘1111’ can the splicing mode be switched by RS-232 instruction
Power Supply
DC12V/2A
Power Consumption
＜9W
Working temperature
-20℃~60℃
Storage temperature
-30℃~70℃
Humidity
0~90%RH（No condensation）
Housing
Iron
Weight
514g
Color
Black
Dimensions
148.5(L)*103.0(W)*25.0(H)mm
Protection
ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
