HDMI Input
1x HDMI
HDMI Output
4x HDMI
Compatibility
HDMI 2.0
HDCP 1.4/HDCP 2.0
Resolutions
Input： 4096x2160@24/25/30/50/60Hz， 3840x2160@24/25/30/50/60Hz， 3440x1440@60Hz，2560x1600@60Hz， 2560x1440@60Hz，2560x1080@60Hz， 1920x1200@60Hz
Output： When the mode is 000/001/010, the maximum output is 1080P@30Hz; other modes have a maximum output of 1080P@60Hz.
Resolutions
Input： 1080P@24/25/30/50/60Hz 720P@50/60Hz
Output： 1080P@24/25/30/50/60Hz
3.5mm Output
LPCM 2.0
HDMI Output
Dolby Digital 5.1CH /DTS 5.1CH/LPCM 2.0
Mode
1x2/1x3/1x4/2x2
RS-232 (GND/ RxD/TxD)
Default baud rate: 9600 Only when the dip switch is set to ‘111’ can the splicing mode be switched by RS-232 instruction
Power Supply
DC12V/2A
Power Consumption
＜8W
Working temperature
-20℃~60℃
Storage temperature
-30℃~70℃
Humidity
0~90%RH（No condensation）
Housing
Iron
Weight
509g
Color
Black
Dimensions
148.5(L)*103.0(W)*25.0(H)mm
Protection
ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
