HDMI length
≤ 5m
Maximum transfer rate
4.96Gbps
Compatibility
HDMI 1.3，HDCP 1.4
Resolutions
1080P@24/25/30/50/60Hz, 720P@50/60Hz, 576P@60Hz, 480P@60Hz, 1920x1200, 1680x1050, 1600x900, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600
Connection types
One-to-one connection
One-to-many connection
Switch cascading
Transmission distance
CAT5 80m / CAT5E 100m / CAT6 120m
Transmission latency
80~130ms
HDMI output
LPCM 2.0
Power Supply
DC 5V/1A
Power Consumption
TX ≤ 3.5W，RX ≤ 3W
Working temperature
- 20℃~60℃
Storage temperature
- 30℃~70℃
Humidity
0~90%RH (no condensation）
Housing
Aluminium(Top cover); lron(Bottom cover)
Weight
TX：160g，RX：160g
Color
Black
Dimensions
110.0(L)*58.0(W)*26.0(H)mm
Protection
ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
